Original price was: £4,995.00.£4,295.00Current price is: £4,295.00.
| MOTOR SPECS | |
| Motor Type | Air cooled permanent magnet synchronous motor |
| Weight / Motor External Diameter | 7.0kg / 180mm |
| Motor axle length | 130mm |
| Peak efficiency | 95.60% |
| Cooling method | Air-Cooled |
| CONTROLLER SPECS | |
| Controller type | Sine wave controller |
| Dimensions | 240mm x 110mm x 50mm |
| Peak efficiency | 98.50% |
| Power modes | Eco and Sport |
| MOTOR POWER SYSTEM SPECS | |
| Rated voltage | 60v (DC) |
| Rated power / peak power | 3,000W / 6,000W |
| Motor shaft output torque @ 1000rpm | 35.40Nm |
| Rated Rotation Speed | 4300rpm |
| Peak efficiency | 97.8% |
| Range of efficiency (≥80) | 1.4Nm – 21.5Nm |
| CERTIFICATES | |
| Road Legal | YES |
| TRANSMISSION SPECS | |
| Gear Ratio | 1:7.6 |
| Transmission | Primary belt & 420 drive chain |
| ELECTRICAL COMPONENTS | |
| Battery | 60V 32A Lithium battery with 176 cells |
| Battery life | 500 cycles (reduces thereafter) |
| Battery charge indicator | Integrated LCD display |
| Charger | 10A |
| Charging time | 2.5 – 3.5 hours |
| USB connection | Single USB 2.1 Type A socket |
| Speedometer | LCD digital speedometer |
| Headlight & rear light | LED |
| VEHICLE SPEC | |
| Chassis & swingarm | Forged aluminium |
| Chassis surface and colour processing | Anodic Oxidation |
| Front suspension | KKE, DNM, RST of Fastace, adjustable for preload & rebound |
| Rear shock absorber | KKE, DNM, RST or Fastace Shock with TR suspension link system. Adjustable for compression & rebound |
| Wheel type & size | 19″ x 1.4 spoked wheels front/rear, Alloy Hubs |
| Tyre size | 70/100 – 19″ front & rear |
| Max Range | 60 miles @ 20mph depending on terrain |
| Net weight | 47kg (plus battery) |
| Maximum load | 100kg (220lbs) |
| Maximum climbing angle | 45° |
| Rear sprocket | 48T (optional 58T available) |
| Side stand | yes, with kill switch |
| Vehicle dimensions | 1870mm x 780mm x1040mm |
| Minimum ground clearance | 270mm |
| Wheelbase | 1260mm |
| Seat height | 84 – 88cm |
